MicroSpider 2 Environmental
Advanced data logging and alarms for the toughest of environments.
The MicroSpider2 Environmental is a compact, low-maintenance telemetry and data logging system, designed to withstand harsh conditions for long-term environmental monitoring. With broad sensor compatibility and flexible data reporting, it enables seamless collection and transmission of critical environmental data.
Key Features
Broad Sensor Compatibility
Supports analog, SDI-12, Modbus RTU, and GPS sensors for versatile environmental monitoring.
Compact & Efficient
Small footprint with rugged IP68 enclosure for installation in tight or exposed locations.
Low Power & Long Battery Life
Powered by 14.4V LiFePO₄ batteries with up to 8 years of life*. Optional solar charging available.
Customisable Data Reporting
Create CSV reports at custom intervals and send via HTTP/HTTPS, FTP, email, or DNP3.
Smart Calculations
Use virtual channels to create derived measurements for tasks like barometric compensation or flow correction without external processing.
Flexible Communications
LTE Cat-M1 with optional Wi-Fi (HLink) or LAN (LANLink). Supports remote alarms via SMS or email.
*(Battery life based on 1-hour logging, daily reports, 1 alarm/week via LTE Cat-M1)
-
Enclosure: IP68‑rated ABS (including connectors)
Size & Weight: 165mm (W) × 145mm (H) × 85mm (D), 800g
Temperature Range: ‑20°C to +60°C
Mounting: Integrated into enclosure
Warranty: 12‑month manufacturer’s warranty
-
Power Supply: 12–22V DC (solar or external)
Battery Type: 14.4V LiFePO₄, replaceable
Optional: Secondary battery for backup
Charging: Built‑in charger for 12V battery & solar panel
Expected Battery Life: Up to 8 years* (low‑power deployments)
-
Standard Inputs:
– 4 × Analogue (0–2.4V / 0–5V / 0–10V / 4–20mA)
– 4 × Digital (switch / event / counter / quadrature)
– 6 × System Inputs (battery voltage ×2, temp, LAN voltage, external power, moisture)Optional Inputs:
– Up to 20 × SDI‑12 & Modbus sensor inputs
– GPSVirtual Inputs:
– 2 × Calculation / logic‑basedOutputs:
– 1 × Switched sensor power/control
– 1 × Open collector (accessory control)
– 1 × Low‑power sensor supply (3.3V or 5V) -
Memory Type: Non-volatile flash
Storage Capacity: ~300,000 records
Report Format: CSV
-
Mobile: 4G LTE Cat-M1
Wired: Ethernet (via LANLink cable)
WiFi: Supported via HLink cable
Protocols:
– HTTP/HTTPS POST
– FTP
– Email
– DNP3Antenna Options: Internal (standard), External (optional)
-
Clock: On‑board Real‑Time Clock (RTC)
Sync: Automatic NTP Synchronisation -
MicroSpider2 Environmental Brochure (MSEF1.0)
MicroSpider2 Environmental Datasheet (MSES1.0)
MicroSpider2 Environmental User Manual
MicroSpider2 Environmental Installation Guide
📎 © 2025 Halytech. Specifications subject to change without notice.
How It Works
-
Mount in any environment and connect your sensors.
-
Use Wi-Fi or LAN to configure inputs, sensors, and reporting.
-
Collect and transmit sensor data at defined intervals.
-
Export CSV reports for decision-making and compliance.
Applications
Environmental Monitoring
Industrial & Water Treatment
Research & Science
Simplify Your Environmental Monitoring
No complicated setups or unreliable readings. MicroSpider2 Environmental offers a small-footprint, fully sealed solution designed for accuracy and reliability.
